| Detail Specification | |
|---|---|
| Memory Technology | Dual Channel DDR5 |
| DIMM Slots | 4 x DDR5 DIMM |
| Supported Memory Types | DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC) |
| Max. System Memory Capacity | 256GB |
| Overclocking Support | Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) |
| CPU PCIe Slots | 1 x PCIe 5.0 x16 (PCIE1), 1 x PCIe 4.0 x4 (PCIE2) |
| Expansion Slot | 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module |
| Graphics | Integrated AMD RDNA™ graphics, supports HDMI 2.1 and DisplayPort 1.4 |
| Audio Codec | Realtek ALC897, 7.1 CH HD Audio, Nahimic Audio |
| LAN | 2.5 Gigabit LAN (Dragon RTL8125BG), Supports Dragon 2.5G LAN Software |
| USB Ports (CPU) | 1 x USB 3.2 Gen2 Type-C, 1 x USB 3.2 Gen2 Type-A |
| USB Ports (Chipset) | 1 x USB 3.2 Gen1 Type-C, 6 x USB 3.2 Gen1 Type-A, 8 x USB 2.0 |
| Rear Panel I/O | 1 x HDMI Port, 1 x DisplayPort 1.4, 1 x USB 3.2 Gen2 Type-A, 1 x USB 3.2 Gen2 Type-C, 2 x USB 3.2 Gen1 Ports, 4 x USB 2.0 Ports, 1 x RJ-45 LAN Port, 1 x BIOS Flashback Button, HD Audio Jacks |
| Storage | 1 x Blazing M.2 Socket (M2_1), 1 x Hyper M.2 Socket (M2_2), 1 x Hyper M.2 Socket (M2_3), 4 x SATA3 6.0 Gb/s Connectors |
| RAID Support | RAID 0, RAID 1, RAID 10 for SATA storage devices and M.2 NVMe storage devices |
| Connectors | 1 x SPI TPM Header, 1 x Power LED and Speaker Header, 1 x RGB LED Header, 3 x Addressable LED Headers, 2 x CPU Fan Connectors, 3 x Chassis Fan Connectors, 1 x 24 pin ATX Power Connector, 1 x 8 pin 12V Power Connector, 1 x 4 pin 12V Power Connector, 1 x Front Panel Audio Connector, 2 x USB 2.0 Headers, 2 x USB 3.2 Gen1 Headers, 1 x Front Panel Type C USB 3.2 Gen1 Header |
| BIOS Feature | 256Mb AMI UEFI Legal BIOS with GUI support |
| Software | ASRock Motherboard Utility (A-Tuning), ASRock Dragon 2.5G LAN Software, ASRock Polychrome SYNC |
| Operating System | Microsoft® Windows® OS 10 64-bit / 11 64-bit |
| Certifications | FCC, CE, ErP/EuP ready |
| Accessories | 2 x SATA Data Cables, 1 x Screw for M.2 Socket, 1 x Thermistor Cable, 1 x Screw for M.2 Socket |
| Platform | Micro ATX Form Factor: 9.6-in x 9.6-in (24.4 cm x 24.4 cm), Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors |
| Unique Features | PCIe Gen5, Dual Channel DDR5, 8+2+1 Power Phase, Dr.MOS, Pre-Installed I/O Shield, 2.5G LAN |
| Chipset | AMD B850 |
